Vibe-Port Wireless Vibration System

The VIBE-PORT-Ethernet is a unique vibration system which allows the transmission of standard vibration and temperature sensors to anywhere in the World. The system then re-forms these signals into standard analogue waveforms at the receiver enabling them to be monitored using any Vibration Data Analyser or collector. These files can also be ‘played’ into any suitable analysis software such as LabView.

At the receiver end PC software allows a timetable of dada collection to be entered and then the software connects to the remote transmitters and obtains approx. 1 minute of raw mV Vibration data from the transmitters selected. the remote transmitter must have an Ethernet connection, via either a local network, cellular connection of satellite link.

The system works with any standard industrial vibration sensors and is ideal for installations where access to the machinery being monitored is difficult due to Health & Safety regulations or remote locations where travel is difficult. It also allows more data to be collected than would normally be financially viable, giving better and more accurate notice of deteriorating assets
